Associate-Cloud-Engineer Google Cloud Certified - Associate Cloud Engineer Questions and Answers

The key to understand the requirement is : "The objects are written once and accessed frequently for 30 days"

Standard Storage

Standard Storage is best for data that is frequently accessed ("hot" data) and/or stored for only brief periods of time.

Archive Storage

Archive Storage is the lowest-cost, highly durable storage service for data archiving, online backup, and disaster recovery. Unlike the "coldest" storage services offered by other Cloud providers, your data is available within milliseconds, not hours or days. Archive Storage is the best choice for data that you plan to access less than once a year.

https://cloud.google.com/storage/docs/storage-classes#standard

M1 machine series Medium in-memory databases such as SAP HANA Tasks that require intensive use of memory with higher memory-to-vCPU ratios than the general-purpose high-memory machine types. In-memory databases and in-memory analytics, business warehousing (BW) workloads, genomics analysis, SQL analysis services. Microsoft SQL Server and similar databases.

https://cloud.google.com/compute/docs/machine-types

https://cloud.google.com/compute/docs/machine-types#:~:text=databases%20such%20as-,SAP%20HANA,-In%2Dmemory%20databases

https://www.sap.com/india/products/hana.html#:~:text=is%20SAP%20HANA-,in%2Dmemory,-database%3F

This command correctly lists pods that have the label app=prod. When creating the deployment, we used the label app=prod so listing pods that have this label retrieve the pods belonging to nginx deployments. You can list pods by using Kubernetes CLI  kubectl get pods.

Ref: https://kubernetes.io/docs/tasks/access-application-cluster/list-all-running-container-images/

Ref: https://kubernetes.io/docs/tasks/access-application-cluster/list-all-running-container-images/#list-containers-filtering-by-pod-label

https://cloud.google.com/kubernetes-engine/docs/concepts/daemonset

https://cloud.google.com/kubernetes-engine/docs/concepts/daemonset#usage_patterns

DaemonSets attempt to adhere to a one-Pod-per-node model, either across the entire cluster or a subset of nodes. As you add nodes to a node pool, DaemonSets automatically add Pods to the new nodes as needed.

In GKE, DaemonSets manage groups of replicated Pods and adhere to a one-Pod-per-node model, either across the entire cluster or a subset of nodes. As you add nodes to a node pool, DaemonSets automatically add Pods to the new nodes as needed. So, this is a perfect fit for our monitoring pod.

Ref: https://cloud.google.com/kubernetes-engine/docs/concepts/daemonset

DaemonSets are useful for deploying ongoing background tasks that you need to run on all or certain nodes, and which do not require user intervention. Examples of such tasks include storage daemons like ceph, log collection daemons like fluentd, and node monitoring daemons like collectd. For example, you could have DaemonSets for each type of daemon run on all of your nodes. Alternatively, you could run multiple DaemonSets for a single type of daemon, but have them use different configurations for different hardware types and resource needs.

An external passthrough Network Load Balancer operates at layer 4 (TCP/UDP) and preserves the original client IP address. This is a key requirement stated in the question. It's also designed for external-facing applications that need to handle TCP or UDP traffic directly without proxying at the application layer.

Option A: An internal passthrough Network Load Balancer is used for load balancing traffic within a Virtual Private Cloud (VPC) network, not for exposing applications to the public internet.

Option C & D: Global and regional external proxy Network Load Balancers operate at layer 7 (HTTP/HTTPS) or use a proxy for TCP/SSL, which means they terminate the client connection at the load balancer and establish a new connection to the backend instances. This does not preserve the original client IP address by default (though there are ways to retrieve it via headers, it's not a direct passthrough).

Reference to Google Cloud Certified - Associate Cloud Engineer Documents:

The different types of Google Cloud Load Balancers, their operating layers (L4 vs. L7), and their capabilities, including client IP preservation, are thoroughly documented in the Google Cloud Load Balancing documentation, a critical area for the Associate Cloud Engineer certification. The distinction between passthrough and proxy load balancers is essential.

Creating and starting a preemptible VM instance This page explains how to create and use a preemptible virtual machine (VM) instance. A preemptible instance is an instance you can create and run at a much lower price than normal instances. However, Compute Engine might terminate (preempt) these instances if it requires access to those resources for other tasks. Preemptible instances will always terminate after 24 hours. To learn more about preemptible instances, read the preemptible instances documentation. Preemptible instances are recommended only for fault-tolerant applications that can withstand instance preemptions. Make sure your application can handle preemptions before you decide to create a preemptible instance. To understand the risks and value of preemptible instances, read the preemptible instances documentation.https://cloud.google.com/compute/docs/instances/create-start-preemptible-instance

Set budgets and budget alerts Overview Avoid surprises on your bill by creating Cloud Billing budgets to monitor all of your Google Cloud charges in one place. A budget enables you to track your actual Google Cloud spend against your planned spend. After you've set a budget amount, you set budget alert threshold rules that are used to trigger email notifications. Budget alert emails help you stay informed about how your spend is tracking against your budget. 2. Set budget scope Set the budget Scope and then click Next. In the Projects field, select one or more projects that you want to apply the budget alert to. To apply the budget alert to all the projects in the Cloud Billing account, choose Select all.https://cloud.google.com/billing/docs/how-to/budgets#budget-scop

gcloud compute ssh ensures that the user’s public SSH key is present in the project’s metadata. If the user does not have a public SSH key, one is generated using ssh-keygen and added to the project’s metadata. This is similar to the other option where we copy the key explicitly to the project’s metadata but here it is done automatically for us. There are also security benefits with this approach. When we use gcloud compute ssh to connect to Linux instances, we are adding a layer of security by storing your host keys as guest attributes. Storing SSH host keys as guest attributes improve the security of your connections by helping to protect against vulnerabilities such as man-in-the-middle (MITM) attacks. On the initial boot of a VM instance, if guest attributes are enabled, Compute Engine stores your generated host keys as guest attributes.

Compute Engine then uses these host keys that were stored during the initial boot to verify all subsequent connections to the VM instance.

Ref: https://cloud.google.com/compute/docs/instances/connecting-to-instance

Ref: https://cloud.google.com/sdk/gcloud/reference/compute/ssh

https://cloud.google.com/compute/docs/disks/local-ssd

Autopilot is more reliable and stable release gives more time to fix issues in new version of GKE

1. Create an ingress firewall rule with the following settings: "¢ Targets: all instances with tier #2 service account "¢ Source filter: all instances with tier #1 service account "¢ Protocols: allow TCP:8080 2. Create an ingress firewall rule with the following settings: "¢ Targets: all instances with tier #3 service account "¢ Source filter: all instances with tier #2 service account "¢ Protocols: allow TCP: 8080

Creating or upgrading a cluster by specifying the version as latest does not provide automatic upgrades. Enable node auto-upgrades to ensure that the nodes in your cluster are up-to-date with the latest stable version.

https://cloud.google.com/kubernetes-engine/versioning-and-upgrades

Node auto-upgrades help you keep the nodes in your cluster up to date with the cluster master version when your master is updated on your behalf. When you create a new cluster or node pool with Google Cloud Console or the gcloud command, node auto-upgrade is enabled by default.

Ref: https://cloud.google.com/kubernetes-engine/docs/how-to/node-auto-upgrades

https://cloud.google.com/compute/docs/instances/managing-instance-access

To set a default cluster for gcloud commands, run the following command: gcloud config set container/cluster CLUSTER_NAMEhttps://cloud.google.com/kubernetes-engine/docs/how-to/managing-clusters?hl=en

https://cloud.google.com/sdk/gcloud/reference/compute/networks/subnets/expand-ip-range

gcloud compute networks subnets expand-ip-range - expand the IP range of a Compute Engine subnetwork gcloud compute networks subnets expand-ip-range NAME --prefix-length=PREFIX_LENGTH [--region=REGION] [GCLOUD_WIDE_FLAG …]

The most direct and recommended way to get a granular breakdown of your Google Cloud costs in BigQuery is to enable Cloud Billing data export to BigQuery when you create or manage your Cloud Billing account. This automatically sets up a daily export of your billing data to a BigQuery dataset you specify.

Option A: Enabling the BigQuery API and managing IAM roles are necessary for interacting with BigQuery, but they don't automatically populate it with Cloud Billing data. Selecting a data location is also important for BigQuery datasets but is a separate step from enabling billing export.

Option B: The BigQuery Data Transfer Service is used for transferring data from various sources into BigQuery, but for Cloud Billing data, the direct export feature is the standard and simpler method.

Option D: Enabling Cloud Billing and linking an account makes billing data available in the Cloud Billing console, but it doesn't automatically export it to BigQuery for detailed analysis. You need to explicitly configure the BigQuery export.

Reference to Google Cloud Certified - Associate Cloud Engineer Documents:

The process of setting up Cloud Billing export to BigQuery is clearly documented in the Google Cloud Billing documentation, which is a fundamental area for the Associate Cloud Engineer certification. Understanding how to access and analyze billing data is crucial for cost management.

Let's analyze each option to find the one that meets the requirements of no startup time for new traffic, two idle instances, and minimal administrative overhead:

A. Unchecking "Serve this revision immediately" and using a traffic simulation tool: Unchecking "Serve this revision immediately" does prevent the new revision from receiving traffic immediately. However, manually using a traffic simulation tool adds administrative overhead. It also doesn't guarantee that two idle instances will be ready before traffic is shifted; you would need to monitor and adjust traffic manually based on the simulation.

B. Configuring service autoscaling and setting the minimum number of instances to 2: Service-level autoscaling applies to all revisions of the service. Setting the minimum instances at the service level would ensure at least two instances are running across all active revisions, not specifically for the new revision before traffic shift.

C. Configuring revision autoscaling for the new revision and setting the minimum number of instances to 2: This is the correct approach. By configuring revision autoscaling specifically for the new revision and setting the minimum number of instances to 2, Cloud Run will ensure that at least two instances of the new version are running and ready to serve traffic before you redirect any traffic to it. This eliminates startup latency when you do shift traffic. It also minimizes administrative overhead as Cloud Run manages the instance scaling based on this configuration.

D. Configuring revision autoscaling for the existing revision and setting the minimum number of instances to 2: This would ensure the existing version has at least two idle instances, which doesn't directly address the requirement of having idle instances ready for the new version before traffic redirection.

Google Cloud Documentation References:

Cloud Run Autoscaling: https://cloud.google.com/run/docs/configuring/min-instances - This document explains how to configure minimum and maximum instances for Cloud Run services and revisions. It clarifies that you can set minimum instances at the revision level to ensure instances are always ready.

Cloud Run Traffic Management: https://cloud.google.com/run/docs/managing/traffic - This describes how to deploy new revisions and gradually shift traffic between them. Combining minimum instances on the new revision with traffic splitting allows for zero-downtime deployments with pre-warmed instances.

===========

Instance groups are collections of virtual machine (VM) instances that you can manage as a single entity. Instance groups can help you simplify the management of multiple instances, reduce operational costs, and improve the availability and performance of your applications. Instance groups support autoscaling, which automatically adds or removes instances from the group based on increases or decreases in load. Autoscaling helps your applications gracefully handle increases in traffic and reduces cost when the need for resources is lower. You can set the autoscaling policy based on CPU utilization, load balancing capacity, Cloud Monitoring metrics, or a queue-based workload. In this case, since the video encoding software is CPU-intensive, setting the autoscaling based on CPU utilization is the best option to ensure high availability and optimal performance. References:

Instance groups

Autoscaling groups of instances

https://cloud.google.com/compute/docs/troubleshooting/troubleshooting-migs

https://cloud.google.com/compute/docs/instance-templates#how_to_update_instance_templates

The reason is that when you do health check, you want the VM to be working. Do the first check after initial setup time of 3 mins = 180 s < 200 s is reasonable.

The reason why our autoscaling is adding more instances than needed is that it checks 30 seconds after launching the instance and at this point, the instance isnt up and isnt ready to serve traffic. So our autoscaling policy starts another instance  again checks this after 30 seconds and the cycle repeats until it gets to the maximum instances or the instances launched earlier are healthy and start processing traffic  which happens after 180 seconds (3 minutes). This can be easily rectified by adjusting the initial delay to be higher than the time it takes for the instance to become available for processing traffic.So setting this to 200 ensures that it waits until the instance is up (around 180-second mark) and then starts forwarding traffic to this instance. Even after a cool out period, if the CPU utilization is still high, the autoscaler can again scale up but this scale-up is genuine and is based on the actual load.

Initial Delay Seconds  This setting delays autohealing from potentially prematurely recreating the instance if the instance is in the process of starting up. The initial delay timer starts when the currentAction of the instance is VERIFYING.

Ref: https://cloud.google.com/compute/docs/instance-groups/autohealing-instances-in-migs

You can deploy to a different project by using –project flag.

By default, the service is deployed the current project configured via:

$ gcloud config set core/project PROJECT

To override this value for a single deployment, use the –project flag:

$ gcloud app deploy ~/my_app/app.yaml –project=PROJECT

Ref:https://cloud.google.com/sdk/gcloud/reference/app/deploy

https://cloud.google.com/resource-manager/docs/project-migration#oauth_consent_screen

https://cloud.google.com/resource-manager/docs/project-migration

Types of audit logs Cloud Audit Logs provides the following audit logs for each Cloud project, folder, and organization: Admin Activity audit logs Data Access audit logs System Event audit logs Policy Denied audit logs *Data Access audit logs contain API calls that read the configuration or metadata of resources, as well as user-driven API calls that create, modify, or read user-provided resource data.https://cloud.google.com/logging/docs/audit#types

https://cloud.google.com/logging/docs/audit#data-access Cloud Storage: When Cloud Storage usage logs are enabled, Cloud Storage writes usage data to the Cloud Storagebucket, which generates Data Access audit logs for the bucket. The generated Data Access audit log has its caller identity redacted.

Configure the ACLs on each image in Cloud Storage to give read-only access to the default Compute Engine service account. is not right.

As mentioned above, Container Registry ignores permissions set on individual objects within the storage bucket so this isnt going to work.

Ref: https://cloud.google.com/container-registry/docs/access-control

https://blog.doit-intl.com/the-truth-behind-google-cloud-egress-traffic-6e8f57b5c2f8

The organization policy explicitly prevents the use of service account keys, so options A and B, which involve requesting exceptions to create them, are not in line with the policy and Google's recommended practices for secure authentication.

According to the Google Cloud documentation, you can use organization policy constraints to control the creation and expiration of service account keys. The constraints are:

constraints/iam.allowServiceAccountKeyCreation: This constraint allows you to specify which projects or folders can create service account keys. You can set the value to true or false, or use a condition to apply the constraint to specific service accounts. By setting this constraint to false for the organization and adding an exception for the pj-sa project, you can prevent developers from creating service account keys in other projects.

constraints/iam.serviceAccountKeyMaxLifetime: This constraint allows you to specify the maximum lifetime of service account keys. You can set the value to a duration in seconds, such as 86400 for one day. By setting this constraint to 86400 for the organization, you can ensure that all service account keys expire after one day.

These constraints are recommended by Google Cloud as best practices to minimize the risk of service account key misuse or compromise. They also help you reduce the cost of managing service account keys, as you do not need to implement a custom solution to rotate or delete them.

1: Associate Cloud Engineer Certification Exam Guide | Learn - Google Cloud

5: Create and delete service account keys - Google Cloud

Organization policy constraints for service accounts

https://cloud.google.com/kuberun/docs/rollouts-rollbacks-traffic-migration

Create an instance template for the instances so VMs have same specs. Set the "˜Automatic Restart' to on to VM automatically restarts upon crash. Set the "˜On-host maintenance' to Migrate VM instance. This will take care of VM during maintenance window. It will migrate VM instance making it highly available Add the instance template to an instance group so instances can be managed.

• onHostMaintenance: Determines the behavior when a maintenance event occurs that might cause your instance to reboot.

• [Default] MIGRATE, which causes Compute Engine to live migrate an instance when there is a maintenance event.

• TERMINATE, which stops an instance instead of migrating it.

• automaticRestart: Determines the behavior when an instance crashes or is stopped by the system.

• [Default] true, so Compute Engine restarts an instance if the instance crashes or is stopped.

• false, so Compute Engine does not restart an instance if the instance crashes or is stopped.

Enabling automatic restart ensures that compute engine instances are automatically restarted when they crash. And Enabling Migrate VM Instance enables live migrates i.e. compute instances are migrated during system maintenance and remain running during the migration.

Automatic Restart  If your instance is set to terminate when there is a maintenance event, or if your instance crashes because of an underlying hardware issue, you can set up Compute Engine to automatically restart the instance by setting the automaticRestart field to true. This setting does not apply if the instance is taken offline through a user action, such as calling sudo shutdown, or during a zone outage.

Ref: https://cloud.google.com/compute/docs/instances/setting-instance-scheduling-options#autorestart

Enabling the Migrate VM Instance option migrates your instance away from an infrastructure maintenance event, and your instance remains running during the migration.Your instance might experience a short period of decreased performance, although generally, most instances should not notice any difference. This is ideal for instances that require constant uptime and can tolerate a short period of decreased performance.

Ref: https://cloud.google.com/compute/docs/instances/setting-instance-scheduling-options#live_migrate

When you intially click on Monitoring(Stackdriver Monitoring) it creates a workspac(a stackdriver account) linked to the ACTIVE(CURRENT) Project from which it was clicked.

Now if you change the project and again click onto Monitoring it would create an another workspace(a stackdriver account) linked to the changed ACTIVE(CURRENT) Project, we don't want this as this would not consolidate our result into a single dashboard(workspace/stackdriver account).

If you have accidently created two diff workspaces merge them under Monitoring > Settings > Merge Workspaces > MERGE.

If we have only one workspace and two projects we can simply add other GCP Project under

Monitoring > Settings > GCP Projects > Add GCP Projects.

https://cloud.google.com/monitoring/settings/multiple-projects

Nothing about groupshttps://cloud.google.com/monitoring/settings?hl=en

A simple approach would be to use the command flags available when listing all the IAM policy for a given project. For instance, the following command: `gcloud projects get-iam-policy $PROJECT_ID --flatten="bindings[].members" --format="table(bindings.members)" --filter="bindings.role:roles/owner"` outputs all the users and service accounts associatedwith the role ‘roles/owner’ in the project in question.https://groups.google.com/g/google-cloud-dev/c/Z6sZs7TvygQ?pli=1

"Billing Account Viewer access would usually be granted to finance teams, it provides access to spend information, but does not confer the right to link or unlink projects or otherwise manage the properties of the billing account."https://cloud.google.com/billing/docs/how-to/billing-access

Let's analyze each option:

A. Using gsutil: While gsutil can transfer data to Cloud Storage, for 150 TB of infrequently accessed data, direct transfer over the network might be slow and consume significant bandwidth, potentially impacting other network operations. It also lacks built-in mechanisms for filtering files based on age.

B. Using Cloud Interconnect and Filestore: Cloud Interconnect provides a dedicated connection, but Filestore is a fully managed NFS service primarily designed for high-performance file sharing for applications running in Google Cloud. Migrating 150 TB of infrequently accessed data to Filestore would be cost-inefficient compared to Cloud Storage and doesn't directly address the requirement of moving older than one year files.

C. Using Transfer Appliance: Transfer Appliance is suitable for very large datasets (petabytes) or when network connectivity is poor or unreliable. While it addresses bandwidth concerns, it involves a physical appliance and might be an overkill for 150 TB of data, especially if network connectivity is reasonable.

D. Using Storage Transfer Service: Storage Transfer Service is specifically designed for moving large amounts of data between online storage systems, including on-premises file systems and Cloud Storage. It offers features like filtering by file age, scheduling transfers, and bandwidth control, directly addressing all the requirements of the question: migrating infrequently accessed files older than one year to Cloud Storage, minimizing costs (by using appropriate Cloud Storage classes for infrequent access), and controlling bandwidth usage.

Google Cloud Documentation References:

Storage Transfer Service Overview: https://cloud.google.com/storage-transfer-service/docs/overview - This page details the capabilities and use cases of Storage Transfer Service, including transferring from on-premises.

Storage Transfer Service for on-premises data: https://cloud.google.com/storage-transfer-service/docs/on-prem-overview - This specifically covers transferring data from on-premises file systems.

Cloud Storage Classes: https://cloud.google.com/storage/docs/storage-classes - Understanding the different storage classes (Standard, Nearline, Coldline, Archive) is crucial for cost optimization of infrequently accessed data. Storage Transfer Service can be configured to move data to a cost-effective class like Nearline or Coldline.

===========

https://gtseres.medium.com/using-service-accounts-across-projects-in-gcp-cf9473fef8f0

You create the service account in proj-sa and take note of the service account email, then you go to proj-vm in IAM > ADD and add the service account's email as new member and give it the Compute Storage Admin role.

https://cloud.google.com/compute/docs/access/iam#compute.storageAdmin

When applied to a dataset, this role provides the ability to read the dataset's metadata and list tables in the dataset. When applied to a project, this role also provides the ability to run jobs, including queries, within the project. A member with this role can enumerate their own jobs, cancel their own jobs, and enumerate datasets within a project. Additionally, allows the creation of new datasets within the project; the creator is granted the BigQuery Data Owner role (roles/bigquery.dataOwner) on these new datasets.

https://cloud.google.com/bigquery/docs/access-control

Folders are nodes in the Cloud Platform Resource Hierarchy. A folder can contain projects, other folders, or a combination of both. Organizations can use folders to group projects under the organization node in a hierarchy. For example, your organization might contain multiple departments, each with its own set of Google Cloud resources. Folders allow you to group these resources on a per-department basis. Folders are used to group resources that share common IAM policies. While a folder can contain multiple folders or resources, a given folder or resource can have exactly one parent.https://cloud.google.com/resource-manager/docs/creating-managing-folders

https://cloud.google.com/spanner/docs/cpu-utilization#recommended-max

"large quantity" : Cloud Storage or BigQuery "files" a file is nothing but an Object

"...we recommend that you enable Cloud Billing data export to BigQuery at the same time that you create a Cloud Billing account. "https://cloud.google.com/billing/docs/how-to/export-data-bigquery

https://medium.com/google-cloud/analyzing-google-cloud-billing-data-with-big-query-30bae1c2aae4

Best practices for persistent disk snapshots

You can create persistent disk snapshots at any time, but you can create snapshots more quickly and with greater reliability if you use the following best practices.

Creating frequent snapshots efficiently

Use snapshots to manage your data efficiently.

Create a snapshot of your data on a regular schedule to minimize data loss due to unexpected failure.

Improve performance by eliminating excessive snapshot downloads and by creating an image and reusing it.

Set your snapshot schedule to off-peak hours to reduce snapshot time.

Snapshot frequency limits

Creating snapshots from persistent disks

You can snapshot your disks at most once every 10 minutes. If you want to issue a burst of requests to snapshot your disks, you can issue at most 6 requests in 60 minutes.

If the limit is exceeded, the operation fails and returns the following error:

https://cloud.google.com/compute/docs/disks/snapshot-best-practices

gcloud deployment-manager deployments create creates deployments based on the configuration file. (Infrastructure as code). All the configuration related to the artifacts is in the configuration file. This command correctly creates a cluster based on the provided cluster.yaml configuration file.

Ref: https://cloud.google.com/sdk/gcloud/reference/deployment-manager/deployments/create

as the instances (normal or preemptible) would be terminated and relaunched if the health check fails either due to application not configured properly or the instances firewall do not allow health check to happen.

GCP provides health check systems that connect to virtual machine (VM) instances on a configurable, periodic basis. Each connection attempt is called a probe. GCP records the success or failure of each probe.

Health checks and load balancers work together. Based on a configurable number of sequential successful or failed probes, GCP computes an overall health state for each VM in the load balancer. VMs that respond successfully for the configured number of times are considered healthy. VMs that fail to respond successfully for a separate number of times are unhealthy.

GCP uses the overall health state of each VM to determine its eligibility for receiving new requests. In addition to being able to configure probe frequency and health state thresholds, you can configure the criteria that define a successful probe.

https://cloud.google.com/architecture/identity/migrating-consumer-accounts

https://cloud.google.com/compute/docs/access/service-accounts#associating_a_service_account_to_an_instance

https://cloud.google.com/appengine/docs/flexible/managing-projects-apps-billing#:~:text=Each%20Cloud%20project%20can%20contain%20only%20a%20single%20App%20Engine%20application%2C%20and%20once%20created%20you%20cannot%20change%20the%20location%20of%20your%20App%20Engine%20application.

Two App engine can't be running on the same project: you can check this easy diagram for more info:https://cloud.google.com/appengine/docs/standard/an-overview-of-app-engine#components_of_an_application

And you can't change location after setting it for your app Engine.https://cloud.google.com/appengine/docs/standard/locations

App Engine is regional and you cannot change an apps region after you set it. Therefore, the only way to have an app run in another region is by creating a new project and targeting the app engine to run in the required region (asia-northeast1 in our case).

Ref: https://cloud.google.com/appengine/docs/locations

Our requirement is to follow Google recommended practices to achieve the end result. Configuring Private Google Access for On-Premises Hosts is best achieved by VPN/Interconnect + Advertise Routes + Use restricted Google IP Range.

Using Cloud VPN or Interconnect, create a tunnel to a VPC in GCP

Using Cloud Router to create a custom route advertisement for 199.36.153.4/30. Announce that network to your on-premises network through the VPN tunnel.

In your on-premises network, configure your DNS server to resolve *.googleapis.com as a CNAME to restricted.googleapis.com is the right answer right, and it is what Google recommends.

Ref: https://cloud.google.com/vpc/docs/configure-private-google-access-hybrid

You must configure routes so that Google API traffic is forwarded through your Cloud VPN or Cloud Interconnect connection, firewall rules on your on-premises firewall to allow the outgoing traffic, and DNS so that traffic to Google APIs resolves to the IP range youve added to your routes.

You can use Cloud Router Custom Route Advertisement to announce the Restricted Google APIs IP addresses through Cloud Router to your on-premises network. The Restricted Google APIs IP range is 199.36.153.4/30. While this is technically a public IP range, Google does not announce it publicly. This IP range is only accessible to hosts that can reach your Google Cloud projects through internal IP ranges, such as through a Cloud VPN or Cloud Interconnect connection. Without having a public IP address or access to the internet, the only way you could connect to cloud storage is if you have an internal route to it.

So Negotiate with the security team to be able to give public IP addresses to the servers is not right. Following Google recommended practices is synonymous with using Googles services (Not quite, but it is  at least for the exam !!).

So In this VPC, create a Compute Engine instance and install the Squid proxy server on this instance is not right.

Migrating the VM to Compute Engine is a bit drastic when Google says it is perfectly fine to have Hybrid Connectivity architectures https://cloud.google.com/hybrid-connectivity.

So,

Use Migrate for Compute Engine (formerly known as Velostrata) to migrate these servers to Compute Engine is not right.

Text Description automatically generated with low confidence

Cloud Functions is Google Cloud’s event-driven serverless compute platform. It automatically scales based on the load and requires no additional configuration. You pay only for the resources used.

Ref: https://cloud.google.com/functions

While all other options i.e. Google Compute Engine, Google Kubernetes Engine, Google App Engine support autoscaling, it needs to be configured explicitly based on the load and is not as trivial as the scale up or scale down offered by Google’s cloud functions.

You write a lifecycle management rule in XML and push it to the bucket with gsutil lifecycle set config-xml-file. is not right.

gsutil lifecycle set enables you to set the lifecycle configuration on one or more buckets based on the configuration file provided. However, XML is not a valid supported type for the configuration file.

Ref: https://cloud.google.com/storage/docs/gsutil/commands/lifecycle

Write a script that runs gsutil ls -lr gs://myapp-gcp-ace-logs/ to find and remove items older than 90 days. Repeat this process every morning. is not right.

This manual approach is error-prone, time-consuming and expensive. GCP Cloud Storage provides lifecycle management rules that let you achieve this with minimal effort.

Write a script that runs gsutil ls -l gs://myapp-gcp-ace-logs/ to find and remove items older than 90 days. Schedule the script with cron. is not right.

This manual approach is error-prone, time-consuming and expensive. GCP Cloud Storage provides lifecycle management rules that let you achieve this with minimal effort.

Write a lifecycle management rule in JSON and push it to the bucket with gsutil lifecycle set config-json-file. is the right answer.

You can assign a lifecycle management configuration to a bucket. The configuration contains a set of rules which apply to current and future objects in the bucket. When an object meets the criteria of one of the rules, Cloud Storage automatically performs a specified action on the object. One of the supported actions is to Delete objects. You can set up a lifecycle management to delete objects older than 90 days. gsutil lifecycle set enables you to set the lifecycle configuration on the bucket based on the configuration file. JSON is the only supported type for the configuration file. The config-json-file specified on the command line should be a path to a local file containing the lifecycle configuration JSON document.

Ref: https://cloud.google.com/storage/docs/gsutil/commands/lifecycle

Ref: https://cloud.google.com/storage/docs/lifecycle

Standard persistent disks are efficient and economical for handling sequential read/write operations, but they aren't optimized to handle high rates of random input/output operations per second (IOPS). If your apps require high rates of random IOPS, use SSD persistent disks. SSD persistent disks are designed for single-digit millisecond latencies. Observed latency is application specific.

Explanation

Run gcloud builds submit tag gcr.io/img-278322/acme_track_n_trace:v1. is the right answer.

This command correctly tags the image as acme_track_n_trace:v1 and uploads the image to the img-278322 project.

Ref: https://cloud.google.com/sdk/gcloud/reference/builds/submit

https://cloud.google.com/sql/docs/postgres

https://developer.mozilla.org/en-US/docs/Web/HTTP/Basics_of_HTTP/MIME_Types#importance_of_setting_the_correct_mime_type

For a web application (typically using HTTP/HTTPS), an Application Load Balancer is the recommended choice as it operates at Layer 7, providing features like content-based routing, SSL termination, and improved security. To expose the application publicly, you would need to use a public DNS zone. An A record in a public DNS zone maps a domain name to the public IP address of the Application Load Balancer. Using a CNAME record would also work but is generally recommended for aliasing one domain name to another, not directly to an IP address.

Option A & B: Network Load Balancers operate at Layer 4 (TCP/UDP) and lack the application-level features of an Application Load Balancer. Private DNS zones are for internal name resolution within your VPC, not for public access.

Option C: While an Application Load Balancer is the correct type, using a private DNS zone wouldn't make the web application publicly accessible.

Reference to Google Cloud Certified - Associate Cloud Engineer Documents:

The best practices for load balancing web applications on Google Cloud, including the use of Application Load Balancers for Layer 7 traffic and the configuration of public DNS records (A or CNAME) for public access, are detailed in the Google Cloud Load Balancing and Cloud DNS documentation, both important for the Associate Cloud Engineer certification.

https://cloud.google.com/bigquery/docs/custom-quotashttps://cloud.google.com/bigquery/pricing#flat_rate_pricing

https://cloud.google.com/monitoring/audit-logging

Install the workload in a compute engine VM, start and stop the instance as needed, because as per the question the VM runs for 30 hours, process can be performed offline and should not be interrupted, if interrupted we need to restart the batch process again. Preemptible VMs are cheaper, but they will not be available beyond 24hrs, and if the process gets interrupted the preemptible VM will restart.

https://cloud.google.com/logging/docs/audit

Data Access audit logs Data Access audit logs contain API calls that read the configuration or metadata of resources, as well as user-driven API calls that create, modify, or read user-provided resource data.

https://cloud.google.com/logging/docs/audit#data-access

Google Cloud Storage Triggers

Cloud Functions can respond to change notifications emerging from Google Cloud Storage. These notifications can be configured to trigger in response to various events inside a bucket—object creation, deletion, archiving and metadata updates.

Note: Cloud Functions can only be triggered by Cloud Storage buckets in the same Google Cloud Platform project.

Event types

Cloud Storage events used by Cloud Functions are based on Cloud Pub/Sub Notifications for Google Cloud Storage and can be configured in a similar way.

Supported trigger type values are:

google.storage.object.finalize

google.storage.object.delete

google.storage.object.archive

google.storage.object.metadataUpdate

Object Finalize

Trigger type value: google.storage.object.finalize

This event is sent when a new object is created (or an existing object is overwritten, and a new generation of that object is created) in the bucket.

https://cloud.google.com/functions/docs/calling/storage#event_types

Forwarding zones Cloud DNS forwarding zones let you configure target name servers for specific private zones. Using a forwarding zone is one way to implement outbound DNS forwarding from your VPC network. A Cloud DNS forwarding zone is a special type of Cloud DNS private zone. Instead of creating records within the zone, you specify a set of forwarding targets. Each forwarding target is an IP address of a DNS server, located in your VPC network, or in an on-premises network connected to your VPC network by Cloud VPN or Cloud Interconnect.

https://cloud.google.com/nat/docs/overview

DNS configuration Your on-premises network must have DNS zones and records configured so that Google domain names resolve to the set of IP addresses for either private.googleapis.com or restricted.googleapis.com. You can create Cloud DNS managed private zones and use a Cloud DNS inbound server policy, or you can configure on-premises name servers. For example, you can use BIND or Microsoft Active Directory DNS.https://cloud.google.com/vpc/docs/configure-private-google-access-hybrid#config-domain

You can generate Windows passwords using either the Google Cloud Console or the gcloud command-line tool. This option uses the right syntax to reset the windows password.

gcloud compute reset-windows-password windows-instance

Ref: https://cloud.google.com/compute/docs/instances/windows/creating-passwords-for-windows-instances#gcloud

You can use the Google Cloud Pricing Calculator to total the estimated monthly costs for each GCP product. You dont incur any charges for doing so.

Ref: https://cloud.google.com/products/calculator

"Google Cloud VPC Network Peering allows internal IP address connectivity across two Virtual Private Cloud (VPC) networks regardless of whether they belong to the same project or the same organization."

https://cloud.google.com/vpc/docs/vpc-peering

while

"Cloud Interconnect provides low latency, high availability connections that enable you to reliably transfer data between your on-premises and Google Cloud Virtual Private Cloud (VPC) networks."

https://cloud.google.com/network-connectivity/docs/interconnect/concepts/overview

and

"HA VPN is a high-availability (HA) Cloud VPN solution that lets you securely connect your on-premises network to your VPC network through an IPsec VPN connection in a single region."

https://cloud.google.com/network-connectivity/docs/vpn/concepts/overview

Managed instance groups offer autoscaling capabilities that let you automatically add or delete instances from a managed instance group based on increases or decreases in load (CPU Utilization in this case). Autoscaling helps your apps gracefully handle increases intraffic and reduce costs when the need for resources is lower. You define the autoscaling policy and the autoscaler performs automatic scaling based on the measured load (CPU Utilization in this case). Autoscaling works by adding more instances to your instance group when there is more load (upscaling), and deleting instances when the need for instances is lowered (downscaling). Ref:https://cloud.google.com/compute/docs/autoscaler

Before you run the gcloud compute instances list command, you need to do two things: authenticate with your user account and set the default project for gcloud CLI.

To authenticate with your user account, you need to run gcloud auth login, enter your login credentials in the dialog window, and paste the received login token to gcloud CLI. This will authorize the gcloud CLI to access Google Cloud resources on your behalf1.

To set the default project for gcloud CLI, you need to run gcloud config set project $my_project, where $my_project is the ID of the project that contains the instances you want to list. This will saveyou from having to specify the project flag for every gcloud command2.

Option B is not recommended, because using a service account key increases the risk of credential leakage and misuse. It is also not necessary, because you can use your user account to authenticate to the gcloud CLI3. Option C is not correct, because there is no such thing as a Cloud Identity user account key. Cloud Identity is a service that provides identity and access management for Google Cloud users andgroups4. Option D is not required, because the gcloud compute instances list command does not depend on the default zone. You can list instances from all zones or filter by a specific zone using the --filter flag.

1: https://cloud.google.com/sdk/docs/authorizing

2: https://cloud.google.com/sdk/gcloud/reference/config/set

3: https://cloud.google.com/iam/docs/best-practices-for-managing-service-account-keys

4: https://cloud.google.com/identity/docs/overview

https://cloud.google.com/sdk/gcloud/reference/compute/instances/list

https://cloud.google.com/iam/docs/job-functions/auditing#scenario_external_auditors

Because if you directly add users to the IAM roles, then if any users left the organization then you have to remove the users from multiple places and need to revoke his/her access from multiple places. But, if you put a user into a group then its very easy to manage these type of situations. Now, if any user left then you just need to remove the user from the group and all the access got revoked

The organization creates a Google group for these external auditors and adds the current auditor to the group. This group is monitored and is typically granted access to the dashboard application. During normal access, the auditors' Google group is only granted access to view the historic logs stored in BigQuery. If any anomalies are discovered, the group is granted permission to view the actual Cloud Logging Admin Activity logs via the dashboard's elevated access mode. At the end of each audit period, the group's access is then revoked. Data is redacted using Cloud DLP before being made accessible for viewing via the dashboard application. The table below explains IAM logging roles that an Organization Administrator can grant to the service account used by the dashboard, as well as the resource level at which the role is granted.

gcloud compute networks subnets expand-ip-range NAME gcloud compute networks subnets expand-ip-range - expand the IP range of a Compute Engine subnetworkhttps://cloud.google.com/sdk/gcloud/reference/compute/networks/subnets/expand-ip-range

"Run gcloud configurations list to start the Compute Engine instances". How the heck are you expecting to "start" GCE instances doing "configuration list".

Each gcloud configuration has a 1 to 1 relationship with the region (if a region is defined). Since we have two different regions, we would need to create two separate configurations using gcloud config configurations create

Ref: https://cloud.google.com/sdk/gcloud/reference/config/configurations/create

Secondly, you can activate each configuration independently by running gcloud config configurations activate [NAME]

Ref: https://cloud.google.com/sdk/gcloud/reference/config/configurations/activate

Finally, while each configuration is active, you can run the gcloud compute instances start [NAME] command to start the instance in the configurations region.

https://cloud.google.com/sdk/gcloud/reference/compute/instances/start
