D-UN-DY-23 Dell Unity Deploy 2023 Exam Questions and Answers

FAST VP (Fully Automated Storage Tiering for Virtual Pools) is a feature that automatically moves data within a storage pool based on the performance requirements and access patterns of the data. FAST VP data relocation runs in the background according to a user-defined schedule and rate. The schedule determines when the data relocation starts and ends, and the rate determines how much system resources are used for the data relocation. Users can set the Fast VP data relocation rate to High, Medium, Low, or None. High means that the data relocation has the highest priority and uses the most system resources, while None means that the data relocation is disabled. Fast VP data relocation does not run at all times, but only during the scheduled window. Fast VP optimizes data placement by moving 256 MB slices between disk tiers, not 1 GB slices. Users cannot enable or disable FAST VP at the LUN level, but only at the storage pool level.

To apply the management IP from the vSphere UnityVSA console, the system administrator must use the svc_initial_config command. This command allows the user to configure the initial network settings for the UnityVSA, such as the management IP address, subnet mask, gateway, and DNS servers. The svc_ipmi command is used to configure the IPMI settings for the UnityVSA, such as the IPMI IP address, username, and password. The svc_change_hw_config command is used to change the hardware configuration of the UnityVSA, such as the number of CPU cores, memory size, and disk size. The svc_inject command is used to inject faults into the UnityVSA for testing purposes.

A drive partnership group is a colle ction of drives of the same drive type that have been combined into a hidden dynamic pool object. Each drive within a dynamic pool can only be part of a single drive partnership group, and a drive will never change the drive partnership group. The maximum size of a drive partnership group is 32 drives, regardless of the drive type or size. When expanding a dynamic pool, the system will automatically create new drive partnership groups as needed, and distribute the drives evenly across the groups.  The number of drive partnership groups in a dynamic pool is equal to the number of drives divided by 32, rounded up to the nearest integer.  References : Dell Unity: Dynamic Pool s 2 , page 5.

 Mixing FC and iSCSI protocols for the same host and array is not supported by Dell EMC Unity. This can cause issues with multipathing, failover, and performance. The best practice is to use one protocol per host and array pair.  If the host needs to access both FC and iSCSI LUNs from different arrays, then separate vSwitches and port groups should be used for each protocol.  References : Dell EMC Unity: Best Practices Gu ide 1 , page 19.

Packet Reflect is a feature that enables the Dell Unity XT system to use the same interface for outbound communication that was used for inbound communication. This feature is useful when the Dell Unity XT system needs to initiate outbound traffic to an external service, such as DNS, NTP, LDAP, or SM TP. By using Packet Reflect, the Dell Unity XT system can avoid routing issues, firewall restrictions, or network address translation problems that may occur when using a different interface for outbound communication. When a NAS server starts outbound tra ffic to an external service, the Dell Unity XT system uses Packet Reflect to send the packets through the same interface that received the packets from the external service. Therefore, the correct answer is D. Uses Packet Reflect for outbound communication .  References :

Dell EMC Unity: NAS Capabilities

Dell EMC Unity: Unisphere Overview

The snapshot option that is set automatically when a pool is configured is the Pool Automatic Deletion Policy. This option determines how the system handles the deletion of snapshots when the pool reaches a certain threshold of capacity utilization. The user can choose between three policies: Never Delete, Delete Oldest, or Delete Lowest Priority. The Total Pool Consumption and the Snapshot Pool Consumption are not snapshot options, but rather metrics that show the amount of pool space consumed by the pool data and the snapshots respectively.

The Unity 380/380F system supports two types of I/O modules: 12 Gb/s SAS back-end and 10 GbE Base-T front-end. The 12 Gb/s SAS back-end module provides connectivity to the disk drives and expansion enclosures, while the 10 GbE Base-T front-end module provides network connectivity to the hosts and clients. The Unity 380/380F system has four I/O module slots, two for each SP. The 12 Gb/s SAS back-end module must be installed in slot 0 of each SP, and the 10 GbE Base-T front-end module can be installed in slot 1 of each SP. Therefore, the correct answer is C. 12 Gb/s SAS 10 GbE Base-T.  References :

Dell EMC Unity: Hardware Information Guide

Dell EMC Unity: Installation Guide

The service task that the administrator should perform to fix the issue with minimal impact is Restart Management Software. This service task restarts the management software on both storage processors without affecting the data services or the host I/O. This can resolve the communication issues between Unisphere and the storage system. Reinitialize, Enable SSH, and Reboot Storage Processor are service tasks that have more impact and risk than Restart Management Software.
