H12-521_V1.0 HCIP-Intelligent Vision V1.0 Questions and Answers

The Cloud Service Platform (CSP) is the underlying infrastructure that manages containers, resources, and services for the intelligent vision platform. Routine maintenance and health checks are essential to ensure the continuous availability of video surveillance services. A comprehensive routine check of the CSP encompasses multiple layers of the system architecture.

First, the License status must be verified to ensure that all intelligent functions and channel capacities remain authorized and active. Second, monitoring CPU and memory usage is critical to identify potential resource bottlenecks that could lead to service instability or video stuttering. Third, for systems deployed in high-availability environments, the Cluster running status (including two-node cluster heartbeat and synchronization) must be checked to ensure failover capabilities are intact. Finally, since the platform utilizes a microservice architecture, checking the CSP and container running status is mandatory to verify that all functional modules (like the VCNAPI or BMU) are active and isolated as intended. By performing these checks regularly, administrators can proactively address issues before they trigger critical system alarms or data loss.

The correct answer is B . T-Shot is an imaging and exposure technology rather than a protocol, compression method, or storage function. The material explicitly states that “M-Q and X-H series omni-data structuring cameras support T-Shot snapshot engine” and further explains that “T-Shot, Huawei's patented exposure technology, enables optimal imaging of targets and vehicles at the same time”

This directly identifies both the nature and purpose of the technology.

From a technical perspective, T-Shot addresses a common problem in complex surveillance scenes where pedestrians, non-motor vehicles, and motor vehicles may appear simultaneously in a single frame but require different exposure treatment. Traditional exposure methods often fail to preserve all such objects properly in one image. T-Shot improves simultaneous target and vehicle imaging quality, which is especially important in mixed urban environments, campuses, and residential areas. Option A is incorrect because T-Shot is not related to video compression. Option C confuses it with an interconnection protocol such as ONVIF. Option D incorrectly describes a storage or indexing function. Therefore, the only correct choice is B .

The correct answer is A because cutting off unnecessary pigtail cables is not a valid waterproofing method and can actually compromise device integrity and long-term reliability. In installation practice, pigtails are retained as part of the camera’s original interface design, and the emphasis is placed on proper handling and protection , not removal. The material specifically warns that “When moving the devices, use hands and do not lift the pigtails” , which reflects that pigtails are treated as protected connection elements rather than disposable parts. It also stresses correct cable outlet orientation, for example, “The strobe light and flash light cannot be installed upside down. The cable outlet must be vertically at the bottom” , showing that water protection relies on installation method and cable routing.

From a field engineering perspective, waterproofing is achieved by sealing exposed connectors with waterproof tape, protecting cable joints thoroughly, and forming a drip loop so water flows away from the connector rather than into it. These are standard outdoor installation controls. Therefore, B, C, and D are all valid anti-water measures, while A is not.

Video structuring is the essential process of converting unstructured video content into searchable, organized data. This capability is integrated across the Huawei Intelligent Vision architecture, existing at both the front-end (cameras) and the back-end (platforms). Huawei's Software-Defined Cameras (SDC) are equipped with professional AI chips, such as the Ascend 310 or Hi3559A, which provide the high-performance processing required to perform this task locally. These AI chips can even replace backend servers to structure full video features, maximizing network-wide intelligent analysis efficiency. By performing structuring at the edge, the system reduces the bandwidth required to transmit full video streams to the central cloud while maintaining real-time awareness.

Simultaneously, Huawei’s intelligent video cloud and big data platforms provide robust back-end structuring capabilities for historical or live video analysis. These platforms utilize advanced algorithms to automatically generate structured data from massive video feeds. As noted in the documentation, video search intelligently analyzes unstructured original video data and automatically generates structured data based on the proper algorithms. This dual-layer approach allows for flexible deployment depending on whether real-time edge processing or high-volume centralized analysis is required for a specific security scenario.

CPU → Central processing unit

GPU → Graphics processing unit

FPGA → Field-programmable gate array

NPU → Neural processing unit

The correct matching is based on the standard definitions of the four processor types used in intelligent vision architecture. A CPU is the central processing unit , which handles general-purpose control, logic execution, and system coordination. A GPU is the graphics processing unit , originally designed for graphics rendering but now widely used for parallel computing tasks. An FPGA is a field-programmable gate array , which can be reconfigured for specific hardware logic functions and is valuable in acceleration and low-latency processing scenarios. An NPU is a neural processing unit , specialized for AI inference and deep-learning operations.

In intelligent vision systems, these processors serve different but complementary roles. The CPU manages operating control and service orchestration. The GPU accelerates highly parallel workloads. The FPGA supports custom hardware logic and fast pipeline processing. The NPU is especially important for AI-based vision services because it is optimized for neural-network computation, target recognition, and inference efficiency. This processor division is fundamental in intelligent camera, edge, and cloud architecture, where workload specialization improves overall system performance and intelligence capability.

Camera cycling, also known as round-robin viewing, is a feature in the intelligent vision system that allows a set of video panes to automatically rotate through different camera feeds at a specified interval. This is a common practice in security monitoring rooms to allow a limited number of monitors to cover a much larger number of cameras.

According to the system logic for the iClient and IVS platform, the cycling function is designed to refresh the content of the active panes. If the number of cameras selected is equal to or less than the number of available video panes, the display remains static because every camera can be shown simultaneously without the need for rotation. To trigger the "cycling" mechanism, the number of cameras in the resource group must exceed the number of panes currently displayed on the screen. Therefore, if you have configured six video panes for camera cycling, you need to select at least 7 cameras so that the system has a "surplus" camera to rotate into one of the panes when the interval timer expires. This ensures that the surveillance personnel see every camera in the group over a period of time, fulfilling the purpose of the round-robin service.

The correct answer is A. TRUE . In IVS deployment practice, background maintenance tasks such as automatic backup can interfere with application installation, service initialization, database operations, and resource locking. For that reason, engineers typically disable automatic backup before beginning installation or deployment on the CSP OM portal. This is consistent with Huawei’s broader operation and maintenance logic, where management-plane activities on the CSP OM portal directly affect application deployment behavior. The material repeatedly uses the CSP OM portal as the control point for cluster and application configuration, for example when engineers need to view BMU-related service addresses through “Application Configuration > Configuration Management > Configuration > Application Name > Two-Node Cluster”

From an implementation perspective, installation requires a stable and uncontested environment. If an automatic backup starts during deployment, file operations, configuration updates, or service restarts may be interrupted, which can lead to incomplete installation or task failure. Therefore, disabling the automatic backup function before IVS installation is a valid preventive measure and should be regarded as a correct statement.

The correct answer is B. FALSE . The statement is internally inconsistent because it says there are nine parts , but then lists more than nine items . More importantly, the construction sequence in the training material is described differently. The document states that civil engineering implementation includes “onsite measurement and routing, site arrangement, foundation pit excavation, lightning protection and grounding, foundation pit bedding, reinforced cage making, foundation template making, concrete casting, concrete maintenance, foundation pit backfilling, handhole making (optional), and trenching and cabling (optional)”

That official sequence does not match the wording in the question exactly. Terms such as construction material entry , ground part connecting , template removal , and muck backfilling are either not stated in the same form or are not presented as part of a fixed nine-step list. From a professional project-delivery viewpoint, foundation construction is indeed a staged civil process, but the exam statement is inaccurate because both the count and the listed procedure names do not align with the material. Therefore, the statement should be judged false.

The correct answers are A, C, and D because camera upgrade operations in the intelligent vision environment include license-related activation , algorithm package upgrade , and software version upgrade , but do not include simply resetting a camera. The material explains that apps on the intelligent camera platform can be “installed, activated, upgraded, and uninstalled online” and that the App Manager “installs, activates, monitors, and upgrades intelligent apps” . It also states that end users can install RPM software packages on SDCs and that “users need to purchase a license file … and load the license file on the SDC” for chargeable apps. This directly supports license loading and algorithm package upgrade as part of operational upgrade handling.

In addition, software version upgrade is a standard maintenance activity, and the material explicitly references upgrade behavior, including “During upgrade within the power module” and version-upgrade scenarios that require recalibration after software changes. Resetting a camera, however, is a recovery or configuration action, not an upgrade action. Therefore, the valid upgrade operations are A, C, and D .

The correct answer is C because the described method exactly matches the definition of horizontal projection used in license plate character area extraction. In license plate recognition, projection methods are commonly used to separate valid character regions from noise and borders. The material states that “Horizontal projection: The binary license plate image is horizontally projected along the Y axis to obtain the longest successive projection segment as the character area. Filter out horizontally successive black lines around the license plate.” This wording is essentially identical to the question, so the method can be identified directly.

From an image-processing perspective, horizontal projection analyzes the pixel distribution across rows to locate the effective vertical range of the character band. This helps remove irrelevant black border lines above and below the plate characters. By contrast, vertical projection is mainly used later to segment individual characters because spaces naturally exist between them. Binary processing is a preprocessing step, not the named segmentation method here, and direction division is not the correct technical term in this context. Therefore, the only correct choice is C. Horizontal projection .

Cloud service network → The IVS1800 connects to the HUAWEI CLOUD service platform over the Internet and allows you to manage devices on the mobile app.

Network for connecting the device to the upper-level video and image management platform → The IVS1800 connects to the IVS3800 platform as an NVR.

Multi-node network → You can manage multiple IVS1800s on the iClient.

Single-node network → The IVS1800 can connect directly to a monitor, using an HDMI cable, to display live or recorded video.

The matching is based on the deployment role of each IVS1800 network type. The cloud service network is the mode used when the IVS1800 connects outward through the Internet to Huawei cloud services for remote device management, so it matches the feature about connection to the HUAWEI CLOUD service platform and mobile-app management. The network for connecting the device to the upper-level video and image management platform is the upstream integration path used when the IVS1800 works under a larger platform such as the IVS3800 , so that feature matches the statement about connecting to the IVS3800 platform as an NVR .

The multi-node network is intended for centralized management of multiple IVS1800 devices, which is why it matches the feature stating that multiple IVS1800s can be managed on the iClient . The single-node network is the standalone deployment model, so it matches the feature where the IVS1800 connects directly to a monitor through HDMI for local live or playback display. This mapping follows the standard Huawei deployment logic of standalone, clustered, upstream-integrated, and cloud-managed operation.

The physical design of a data center for intelligent vision systems involves strategic placement of network switches to optimize cabling and performance. Two common architectures are Top of Rack (TOR) and End of Row (EOR). In a TOR deployment, Top of Rack (TOR) switches are deployed on the top of each cabinet and used for communication between servers in each cabinet and the external network . This approach minimizes the length of copper cabling within the rack and simplifies the expansion of individual cabinets.

Conversely, the EOR architecture centralizes the switching infrastructure. In this setup, End of Row (EOR) switches are deployed in the last cabinet at each row, and servers in all cabinets at each row are connected to switches through horizontal cabling . While EOR can simplify management by centralizing hardware, it requires significant horizontal cabling across the row. Huawei’s IVS planning recommendations specify that the management port and service ports of hardware devices (like the Taishan 200) connect to these switches. Specifically, the "Management TOR" handles the management plane (often using CE5800 series), while the "Service TOR" handles the high-bandwidth 10 GE service plane (often using CE6800 series), with both eventually aggregating through the EOR switch to connect to the wider customer network.

The correct answer is B. FALSE . The installation guidance in the material does confirm that radar is used in “highway scenarios and accurate speed estimation scenarios” and includes alignment steps such as “Adjust the bubble level. When the bubble is in the center, the radar is horizontal” . However, the statement is too absolute because it says the radar is placed right above the lane , which is not a general rule for radar deployment.

In real highway and checkpoint engineering, radar installation depends on the capture model, lane layout, pole position, and the coordination between radar and camera fields of view. The key requirement is that the detection area be aligned correctly with the intended capture zone, not that the radar must always be mounted directly above the lane center. Many practical deployments use side-mounted or offset positions on poles or beams so the radar can still cover the target lane accurately while matching the camera’s observation geometry. Since the essential requirement is proper alignment with the capture area rather than mandatory overhead placement, the statement as written is inaccurate.

The correct answers are A, C, and D . In IVS3800 architecture, the distinction between management nodes and service nodes is based on whether the node carries the platform’s management container set, especially the CSPOM role. A management node is the server that contains the management component, while a service node is the server that does not contain that management component and instead focuses on service workloads. This is why C and D are correct from the node-role definition perspective.

The cluster nature of the management role is also consistent with the platform design. The training material repeatedly refers to BMU and management addressing in two-node cluster mode , for example: “If the BMU is deployed in two-node cluster mode, enter the external service floating IP address of the BMU” and similarly references external management floating IP handling for clustered upper-level nodes . This reflects that the management layer is designed around clustered high-availability deployment, supporting A . By contrast, B is not accepted because an IVS3800 system made up of only management nodes would lack the service-bearing nodes needed to deliver actual intelligent vision workloads. Therefore, A, C, and D are the correct statements.

For the routine maintenance and health monitoring of an intelligent vision system, administrators rely on specific diagnostic tools to ensure all components are functioning optimally. While "Alarms" alert users to immediate faults and "Logs" provide a historical record of system events, the Inspection function is designed for proactive and comprehensive system health checks.

This specialized tool is used to monitor the "pulse" of the entire platform. According to the maintenance standards, the Inspection function can check the overall system information, including the resource running status and basic database information . This includes verifying the CPU and memory utilization of service nodes, checking the connectivity of storage volumes, and ensuring that the underlying database—which stores critical metadata like target recognition results and system configurations—is responsive and healthy. Regular inspections are a cornerstone of ultra-simplified O & M (Operations and Maintenance), allowing technicians to identify performance bottlenecks or minor inconsistencies before they escalate into critical alarms. By consolidating system-wide resource data and database status into a single inspection report, the IVS platform enables administrators to maintain a stable environment for continuous intelligent analysis and data structuring.
