All four options are recognized terminal identification methods. MAC OUI examines the first three bytes of a device’s MAC address to determine its manufacturer, although it generally cannot identify the exact model or operating system. DHCP option identification analyzes fields such as DHCP options 12, 55, and 60, which can reveal the hostname, parameter-request list, vendor class, and other terminal characteristics. SNMP query is an active identification method that retrieves device details from relevant MIB objects and is particularly useful for printers, network devices, and other SNMP-capable equipment.

Nmap is also an active scanning method. It analyzes open ports, service responses, protocol behavior, and operating-system fingerprints to estimate a terminal’s device type and OS. Huawei distinguishes information-reporting methods from proactive scanning methods: MAC OUI and DHCP options generally use information observed in traffic, whereas SNMP and Nmap actively query or scan the endpoint. iMaster NCE-Campus can correlate multiple fingerprints to improve identification accuracy and automatically apply terminal-specific access policies.

==================

Non-authenticated terminals can access a virtual network by using statically configured VLANs. Such terminals may include printers, cameras, sensors, industrial devices, and other dumb terminals that cannot perform 802.1X, Portal, or comparable interactive authentication. Their access interfaces and service VLANs are therefore configured in advance and mapped to the required VN.

Dynamic VLAN authorization requires a completed authentication or identification process. Normally, an authentication server returns a VLAN or other authorization attribute after validating the user or terminal. Because the question specifically refers to non-authenticated terminals, dynamically authorizing a VLAN is not the applicable mechanism. The wired-mode and wireless-mode authorization options are likewise associated with authentication-based policy delivery rather than unconditional VN access.

Huawei’s VN design guidance states that LAN-side physical interfaces and VLANs are assigned to the appropriate departments or services and then associated with corresponding VRFs or VNs. It also explains that a department may use an independent physical interface or share an interface while maintaining isolation through VLANs. Therefore, configuring a static VLAN is the correct method.

==================

The distinguishing function supported by the AR6177 is VDSL. VDSL, or Very-high-bit-rate Digital Subscriber Line, enables a branch router to obtain WAN connectivity over existing copper telephone infrastructure. It is appropriate for small branches and distributed sites where Ethernet private lines, fiber, or mobile connections are unavailable or commercially impractical.

The AR6177 can terminate the VDSL access circuit and provide routing, NAT, DHCP, VPN, and other branch-gateway functions for the connected LAN. In this single-answer question, Wi-Fi and PoE are not the defining integrated capabilities of the AR6177 model. Similarly, the complete combination of IPS, antivirus, and URL filtering belongs to a security-enhanced product profile rather than the function used to distinguish the AR6177.

Huawei’s campus design material recognizes DSL links as a specific WAN-access category and notes that deployments involving complex or low-speed links, including DSL, may require an appropriate branch-device deployment method. The model is therefore selected when direct VDSL-based WAN access is required. Consequently, VDSL is the supported capability intended by this question, and option C is correct.

==================

The AirEngine 6776I-X6TH is the model designed to provide PCIe card-based IoT expansion. The PCIe interface enables an appropriate IoT expansion card to be installed so that the AP can support additional wireless or sensing technologies according to the deployment requirement. This allows the same physical access infrastructure to deliver enterprise Wi-Fi and IoT connectivity.

The capability is useful in retail, healthcare, education, manufacturing, and asset-management environments, where technologies such as Bluetooth, RFID, Zigbee, electronic shelf labels, location services, or specialized sensing systems may need to coexist with the WLAN. A modular card design is preferable when an organization requires selectable or upgradeable IoT functions rather than only fixed integrated capabilities.

Huawei’s Wi-Fi and IoT convergence architecture reduces repeated cabling, separate power systems, and independently managed wireless networks. It enables an IoT-capable AP to provide the installation position, power, management connectivity, and uplink data channel required by IoT modules. Among the models listed, the AirEngine 6776I-X6TH is the PCIe card-based IoT model. Therefore, option A is correct.

==================

The statement is true. In this three-layer campus design, aggregation switches function as VXLAN edge nodes and distributed gateways, while access switches provide terminal connectivity. Policy association allows the access switches to participate in user admission and policy enforcement without requiring them to support full VXLAN functions.

The access switch collects terminal access information and associates user traffic with the appropriate service or policy. The aggregation switch, acting as the fabric edge and VXLAN tunnel endpoint, performs VXLAN encapsulation, distributed gateway forwarding, and policy-related operations. Huawei specifically states that when aggregation switches operate as edge nodes, access switches do not need to support VXLAN and can cooperate with aggregation switches through policy association. This also permits legacy access switches to be reused.

The design reduces upgrade costs and avoids extending complex overlay configurations to every access device. Huawei’s automated virtual-network deployment model also explicitly includes policy association between the aggregation and access layers, allowing access switches without VXLAN capability to operate as transparent or associated access nodes. Therefore, option A is correct.

==================

iMaster NCE-Campus primarily improves the operations and maintenance experience in this solution. It provides centralized planning, deployment, configuration, policy orchestration, monitoring, topology management, device management, alarm handling, and maintenance through a unified graphical interface.

Instead of configuring each switch, AP, WAC, firewall, or router separately, administrators can define services and policies centrally and deliver them across the network. Huawei states that iMaster NCE-Campus provides integrated LAN and WAN management, integrated deployment, integrated policies, and integrated O & M, thereby improving deployment and O & M efficiency. It also provides network monitoring, service alarms, file management, log management, device maintenance, user management, and virtual-network management from one platform.

Wireless, wired, and application experience analysis is more directly associated with iMaster NCE-CampusInsight, which uses telemetry, AI, protocol tracing, and predictive analysis to quantify user and application experience. iMaster NCE-Campus serves as the management and control platform that simplifies administrators’ daily work. Therefore, the experience specifically improved by iMaster NCE-Campus is the O & M experience, making option C correct.

==================

An industrial RedBox can provide all four listed interconnection modes. In HSR-SAN mode, it connects a singly attached node that does not natively support High-availability Seamless Redundancy to an HSR network. The RedBox duplicates frames entering the HSR domain and removes duplicate frames before delivering traffic to the SAN.

HSR-PRP mode interconnects an HSR ring with a Parallel Redundancy Protocol network while preserving seamless redundancy. PRP-PRP mode couples two PRP network domains, while HSR-HSR mode connects separate HSR rings. Depending on the implementation, the HSR-HSR interconnection function may also be described as a QuadBox function because four HSR-facing ports can be involved.

The essential RedBox responsibilities are frame conversion, duplication, duplicate elimination, sequence-number handling, and prevention of unintended forwarding loops between redundancy domains. HSR and PRP use compatible duplicate-identification principles, enabling controlled interconnection between these network types without introducing a single point of failure. RedBoxes also provide redundant connectivity for devices that have only one ordinary Ethernet interface.

==================

A border device, or more precisely a device at a border site, provides communication between different areas in a hierarchical SD-WAN topology. The hierarchical model divides a large WAN into multiple areas. Each area can independently use a hub-spoke or full-mesh topology, while selected border sites connect the local area to a centralized backbone area.

When a non-border site receives a route originating in another area, the route’s next-hop site ID is changed to the border site in its own area. The local border device then forwards traffic toward the border site in the destination area or toward an interconnected hub site. Ordinary edge devices provide connectivity for their own sites but do not automatically perform cross-area transit.

Huawei describes border sites as members of both the level-2 area network and the level-1 backbone network. These sites collectively implement interconnection between areas. Huawei further explains that inter-area routes point to border sites and recommends two border sites operating in active/standby mode for reliability. Therefore, the correct answer is B.

==================

MRA, or Media Redundancy Auto-Manager, supports the automatic election of the Media Redundancy Manager in an MRP ring. When several devices are configured with the MRA role, they exchange control information and elect one device to perform the MRM function. The elected MRM supervises the ring, blocks one ring port during normal operation to prevent a Layer 2 loop, detects failures, and changes the forwarding state when the ring becomes open.

An MRC is a Media Redundancy Client. It participates in the MRP ring and forwards MRP control packets, but it does not initiate the automatic manager-election process. MRM represents the operational manager role after election or manual configuration, rather than the role specifically designed to support election. MIM refers to a Media Redundancy Interconnection Manager, which is associated with interconnecting and protecting multiple MRP rings rather than electing the manager within one ring. MRP itself distinguishes the ring manager from ring clients and uses the manager to control ring forwarding and recovery.

==================

Option C is false. The digital-map energy-saving function provides network-wide energy visibility, identifies periods of low wireless demand, and recommends appropriate energy-saving time windows. During an approved energy-saving period, selected wireless APs or radio resources can be placed into an energy-saving state after the system evaluates coverage, traffic, and capacity requirements.

Automatically powering off switches is not the intended function. Campus switches may carry essential wired services, provide uplinks for other network devices, and supply PoE power to APs, cameras, phones, sensors, and access-control systems. Automatically shutting down a complete switch could therefore interrupt many unrelated services and potentially disconnect downstream network segments.

Huawei identifies low-carbon and energy-saving operation as a characteristic of cloud campus networks and combines this objective with AI-based intelligent O & M and proactive optimization. Its intelligent O & M architecture analyzes AP load trends and performs predictive wireless-network optimization, providing the analytical foundation for selecting safe energy-saving periods and resources.

Therefore, A, B, and D describe supported digital-map energy-saving capabilities. Automatic switch power-off is the false statement, making C correct.

Enabling the GRE checksum is optional. A functional point-to-point GRE tunnel requires a tunnel interface, GRE as the tunnel protocol, and reachable source and destination tunnel endpoints. The source identifies the local interface or IP address used to construct the delivery header, while the destination identifies the remote GRE endpoint. Without these endpoint parameters, the device cannot correctly encapsulate and deliver packets to the peer.

The checksum field is controlled by the Checksum Present bit in the GRE header. When checksum processing is enabled, the sender includes a checksum covering the GRE header and payload, and the receiver verifies it. This can provide additional corruption detection, but it increases processing and is not required for basic GRE operation. RFC 2784 explicitly labels the checksum field as optional and states that it is present only when the Checksum Present bit is set.

Huawei SD-WAN uses GRE or GRE over IPsec to establish data channels between edge devices. The essential tunnel and transport-network information is distributed through the control system, while optional GRE functions such as checksum validation may be enabled according to operational requirements.

==================

For the R024C10 software release specified in the question, the AR6700V-L cannot be deployed on Google Cloud Platform. The supported environments represented by this release and question are Amazon Web Services, Oracle Cloud, and Microsoft Azure.

Public-cloud support for a virtual CPE is release-specific. A virtual router requires more than generic virtual-machine compatibility. Huawei must provide or validate the appropriate cloud image, virtual network-interface drivers, deployment template, bootstrap mechanism, licensing integration, resource specifications, and controller-registration process for each cloud platform. Therefore, support for one KVM- or VMware-based environment does not automatically mean that every public-cloud provider is supported.

A cloud-hosted virtual CPE enables branches to establish overlay connectivity directly with cloud workloads and allows the controller to provide unified management and policy orchestration for physical and virtual edge devices. Huawei describes this model as deploying a virtual SD-WAN router on a public cloud to implement branch-to-cloud interconnection and unified policy orchestration. Under the R024C10 compatibility matrix tested by this question, GCP is excluded. Therefore, option B is correct.

==================

Huawei SD-WAN provides all four technologies. Per-flow load balancing distributes separate application flows among multiple links that have the same priority and satisfy the required SLA. Per-packet load balancing can transmit packets from one flow across multiple eligible links, improving aggregate bandwidth utilization for large file transfers, backups, and replication.

Multi-fed and selective receiving duplicates critical traffic across different links. The receiving device selects valid packets, removes duplicates, and preserves packet order. Packet loss or failure on one path therefore does not interrupt the service, enabling zero-millisecond link switchover in applicable deployments.

A-FEC dynamically generates redundant packets and adjusts the redundancy ratio according to measured packet loss. The receiving device reconstructs lost packets, reducing video freezing and voice-quality deterioration. Huawei describes both adaptive FEC and multi-fed selective receiving as WAN-optimization mechanisms for key traffic.

Intelligent traffic steering selects links according to application identity, quality, bandwidth, priority, and load. Therefore, A, B, C, and D are all correct.

==================

SM4 is the supported SM-series cryptographic algorithm intended by this question. SM4 is a standardized symmetric block cipher that uses a 128-bit block size and a 128-bit key. It is suitable for high-volume data encryption because symmetric cryptography can process service traffic efficiently compared with public-key algorithms.

Within an SD-WAN or IPsec context, the bulk traffic carried through secure data channels requires a symmetric encryption algorithm. SM4 can therefore be used as the encryption component of an approved cryptographic suite where compliance with Chinese commercial cryptography requirements is necessary.

SM2 is an asymmetric public-key cryptographic suite used for functions such as digital signatures, key exchange, and public-key encryption. It is not the bulk data-encryption algorithm requested in this item. SM1 is a restricted proprietary algorithm whose implementation details are not publicly standardized in the same manner, while SM5 is not the supported option represented by the Huawei course question.

Huawei’s SD-WAN architecture uses IPsec to protect site-to-site services and supports secure GRE-over-IPsec data channels between edge devices. In the SM-series selection presented here, the correct supported traffic-encryption algorithm is SM4.

==================

A terminal-type survey primarily determines the appropriate network admission control solution. Different terminal categories have different authentication capabilities and security requirements. Corporate laptops may support 802.1X authentication, guests may require Portal authentication, and printers, cameras, sensors, and other dumb terminals commonly require MAC-address authentication or automatic terminal identification.

Huawei recommends selecting authentication technologies according to the terminal type and usage scenario. For example, access switches can serve as authentication points for wired dumb terminals, while APs or other access devices can perform authentication for wireless users. After terminal identification is enabled, iMaster NCE-Campus can automatically assign VLANs, ACLs, security groups, QoS parameters, and other authorization policies according to terminal category.

The survey therefore establishes which endpoints support interactive authentication, which require non-interactive admission, and which must receive special isolation or compliance policies. It does not independently determine the complete physical network architecture or the overall O & M platform. Consequently, the terminal survey is used to formulate the network admission control solution, making option C correct.

==================
