NSE6_FAC-6.4 Fortinet NSE 6 - FortiAuthenticator 6.4 Questions and Answers

Two features of FortiAuthenticator that are used for EAP deployment are certificate authority and RADIUS server. Certificate authority allows FortiAuthenticator to issue and manage digital certificates for EAP methods that require certificate-based authentication, such as EAP-TLS or PEAP-EAP-TLS. RADIUS server allows FortiAuthenticator to act as an authentication server for EAP methods that use RADIUS as a transport protocol, such as EAP-GTC or PEAP-MSCHAPV2.

References: https://docs.fortinet.com/document/fortiauthenticator/6.4.0/administration-guide/906179/wireless-802-1x-authentication

enable guest portal services on FortiAuthenticator, you need to configure a portal policy that defines the conditions for presenting the guest portal to users and the authentication methods to use. You also need to configure at least one post-login service that defines what actions to take after a user logs in successfully, such as sending an email confirmation, assigning a VLAN, or creating a user account. Configuring a RADIUS client or an external authentication portal are optional steps that depend on your network setup and requirements. References: https://docs.fortinet.com/document/fortiauthenticator/6.4/administration-guide/372404/guest-management

FortiAuthenticator can create two types of digital certificates: user certificates and local service certificates. User certificates are issued to users or devices for authentication purposes, such as VPN, wireless, or web access. Local service certificates are issued to FortiAuthenticator itself for securing its own services, such as HTTPS, RADIUS, or LDAP.

References: https://docs.fortinet.com/document/fortiauthenticator/6.4.0/administration-guide/906179/certificate-management#certificate-types

CRLs are lists of certificates that have been revoked by the issuing CA and should not be trusted by any entity. CRLs contain the serial number of the certificate that has been revoked, the date and time of revocation, and the reason for revocation. Revoked certificates are automatically placed on the CRL by the CA and the CRL is updated periodically. CRLs can be exported through various methods, such as HTTP, LDAP, or SCEP. Each local CA has its own CRL that is specific to its issued certificates. References: https://docs.fortinet.com/document/fortiauthenticator/6.4/administration-guide/372408/certificate-management/372413/certificate-revocation-lists

FortiAuthenticator is a user and identity management solution that provides strong authentication, wireless 802.1X authentication, certificate management, RADIUS AAA (authentication, authorization, and accounting), and Fortinet Single Sign-On (FSSO). It also offers portal services for guest management, self-service password reset, and device registration. It is not a log server or an RSSO server. References: https://docs.fortinet.com/document/fortiauthenticator/6.4/release-notes

Realms are a way to delegate user accounts, user groups and permissions per domain when they are authenticating on a single FortiAuthenticator device. A realm is a logical grouping of users and groups based on a common attribute, such as a domain name or an IP address range. Realms allow administrators to apply different authentication policies and settings to different groups of users based on their realm membership.

References: https://docs.fortinet.com/document/fortiauthenticator/6.4.0/administration-guide/906179/user-management#realms

The best method to migrate local users from one FortiAuthenticator device to another is to export the users from the current device as a CSV file and then import the CSV file into the new device. This method preserves all the user attributes and settings and allows you to modify them if needed before importing. The other methods are not suitable for migrating local users because they either require an external RADIUS server or do not transfer all the user information. References: https://docs.fortinet.com/document/fortiauthenticator/6.4/administration-guide/372409/user-management

To deploy three FortiAuthenticator devices to provide active-passive HA at headquarters, with geographically distributed load balancing, the role settings would be:

One standalone primary, which acts as the master device for HA and load balancing

One cluster member, which acts as the backup device for HA and load balancing

One load balancer, which acts as a remote device that forwards authentication requests to the primary or cluster member device

References: https://docs.fortinet.com/document/fortiauthenticator/6.4.0/administration-guide/906179/high-availability#ha-and-load-balancing

FortiAuthenticator can help facilitate the process of replacing an existing RADIUS server by enabling learning mode in the RADIUS server configuration. This allows FortiAuthenticator to learn user credentials from the existing RADIUS server and store them locally for future authentication requests2. This way, FortiAuthenticator can gradually take over the role of the RADIUS server without disrupting the user experience.

References: 2 https://docs.fortinet.com/document/fortiauthenticator/6.4.0/administration-guide/906179/radius-service#learning-mode

 To enable guest portal services on FortiAuthenticator, you need to configure a portal policy that defines the conditions for presenting the guest portal to users and the authentication methods to use. You also need to configure at least one post-login service that defines what actions to take after a user logs in successfully, such as sending an email confirmation, assigning a VLAN, or creating a user account. Configuring a RADIUS client or an external authentication portal are optional steps that depend on your network setup and requirements. References: https://docs.fortinet.com/document/fortiauthenticator/6.4/administration-guide/372404/guest-management

HTTPS and SSH are the default management access protocols for administrative access for FortiAuthenticator. HTTPS allows administrators to access the web-based GUI of FortiAuthenticator using a web browser and a secure connection. SSH allows administrators to access the CLI of FortiAuthenticator using an SSH client and an encrypted connection. Both protocols require the administrator to enter a valid username and password to log in.

References: https://docs.fortinet.com/document/fortiauthenticator/6.4.0/administration-guide/906179/system-settings#management-access
