Modify the trust on : DC2

Modify the permissions for the : Computer object of SRV1

In an Active Directory Domain Services (AD DS) environment involving multiple forests and external trusts, managing granular access across domain boundaries is achieved through Selective Authentication . According to official documents for Administering Windows Server Hybrid Core Infrastructure, there are two primary authentication settings for a trust: Domain-wide authentication and Se lective authentication .

When you need to restrict users from a trusted forest (contoso.com) so they can only access specific resources in the trusting forest (adatum.com), you must configure the trust to use Selective Authentication . This configuration must be performed in the resource domain (the trusting domain). Based on the provided table, DC2 is the domain controller for adatum.com , which is where the shared resources (SRV1) reside. Therefore, you must modify the trust properties on DC2 to enable Selective Authentication for the incoming trust from contoso.com.

Once Selective Authentication is enabled, Windows does not automatically grant the " Authenticated Users " SID to the user ' s access token for resources in the local domain. Instead, administrators must explicitly grant the Allowed to Authenticate permission on the specific resource ' s computer object. In this scenario, since the requirement is to restrict access specifically to resources on SRV1 , you must modify the security permissions on the Comput er object of SRV1 in Active Directory Users and Computers. By granting the contoso.com users (or a group containing them) this permission, they can successfully authenticate against SRV1 while being blocked from all other servers in the adatum.com forest. This satisfies the requirement to prevent access to any other resources while maintaining the ability of adatum.com users to access contoso.com (as the 2-way trust remains intact).

To deploy a n ew primary DNS zone named fabrikam.com to DC1 and sign the zone, you can follow these steps:

Step 1: Create the Primary DNS Zone Use the Add-DnsServerPrimaryZone PowerShell command to create the primary zone:

Add-DnsServerPrimaryZone -Name " fabrikam.com " -ZoneFile " fabrikam.com.dns " -DynamicUpdate Secure

This command creates a primary zone for fabrikam.com with a DNS file named fabrikam.com.dns and allows secure dynamic updates.

Step 2: Sign the Zone To sign the zone, you can use the DNS Manager or Windows PowerShell. Here’s how to sign the zone using PowerShell:

Add-DnsServerSigningKey -ZoneName " fabrikam.com " -Type KeySigningKey -CryptoAlgorithm RsaSha256

Set-DnsServerDnsSecZoneSetting -ZoneName " fabrikam.com " -DenialOfExistence NSEC3 -NSEC3Parameters 1,0 ,10, " "

These commands add a signing key to the zone and set DNSSEC settings with NSEC3 parameters.

Step 3: Publish the Signed Zone After signing the zone, ensure that it is published and available for DNS queries. You can verify the zone signing status usi ng the following command:

Get-DnsServerZone -Name " fabrikam.com "

Note: Ensure that you have the appropriate permissions to perform these actions on DC1 and that the DNS Server role is installed and properly configured. Also, replace " fabrikam.com.dns " with the actual path to your DNS file if it’s different12.

By following these steps, you should be able to deploy and sign the new primary DNS zone fabrikam.com on DC1.

To use Azure File Sync to replicate the contents of C:\app on SRV1 to an Azure file share named sharel1, with the source files located in \\dc1.contoso.com\install, follow these steps:

Step 1: Prepare Windows Server for Azure File Sync Ensure that SRV1 meets the prerequisites for Azure File Sync, such as having a supported version of Windows Server and PowerShell 5.1 or later1.

Step 2: Deplo y the Storage Sync Service In the Azure portal, deploy the Storage Sync Service in the same region as your Azure file share1.

Step 3: Create an Azure File Share Create an Azure file share named sharel1 in your storage account1.

Step 4: Install the Azure Fi le Sync Agent Download and install the Azure File Sync agent on SRV11.

Step 5: Register SRV1 with the Storage Sync Service After installing the agent, register SRV1 with the Storage Sync Service using the Azure portal1.

Step 6: Create a Sync Group and Serv er Endpoint In the Azure portal, go to your Storage Sync Service and create a new sync group. Add a server endpoint with the path C:\app on SRV12.

Step 7: Configure Cloud Endpoint Add the Azure file share sharel1 as the cloud endpoint to the sync group2.

S tep 8: Initiate the Sync Process The initial sync will start automatically after the cloud endpoint and server endpoint are added to the sync group. Ensure that the Azure File Sync agent is running on SRV11.

Step 9: Monitor the Sync Status Monitor the sync status in the Azure portal to ensure that the files are being replicated correctly from C:\app on SRV1 to the Azure file share sharel11.

Note: Make sure that the network connectivity between SRV1 and the Azure file share is established and that the necess ary ports are open. Also, verify that the SMB security settings allow for the required SMB protocol version and authentication methods1.

By following these steps, you should be able to replicate the contents of C:\app on SRV1 to the Azure file share sharel 1 using Azure File Sync. Ensure that you have the necessary permissions to perform these actions and that SRV1 is properly configured to communicate with Azure services.
